Глава 1. Кинематика. Параграф 4. Перемещение при равномерном прямолинейном движении по плоскости. Упражнения - номер 2, страница 26.
App\Models\Task {#1030 // resources/views/models/task/default.blade.php #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438068 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1037 #items: array:1 [ 0 => App\Models\Term {#1036 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 26 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "номер" "field_cases" => array:6 [ "field_accusative_case" => "номер" "field_creative_case" => "номером" "field_dative_case" => "номеру" "field_genitive_case" => "номера" "field_nominative_case" => "номер" "field_prepositional_case" => "номере" ] "field_short_name" => "№" ] #original: array:6 [ "id" => 26 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "номер" "field_cases" => array:6 [ "field_accusative_case" => "номер" "field_creative_case" => "номером" "field_dative_case" => "номеру" "field_genitive_case" => "номера" "field_nominative_case" => "номер" "field_prepositional_case" => "номере" ] "field_short_name" => "№" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1035 #items: [] #escapeWhenCastingToString: false } "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1046 #items: array:1 [ 0 => App\Models\Branch {#1045 #connection: "mysql" #table: "branches" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1437875 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Кинематика" "field_branch_order" => "1" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1050 #items: array:1 [ 0 => App\Models\Term {#1047 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:7 [ "id" => 29 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Глава" "field_cases" => array:6 [ …6] "field_page_check_not_needed" => null "field_short_name" => null ] #original: array:7 [ "id" => 29 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Глава" "field_cases" => array:6 [ …6] "field_page_check_not_needed" => null "field_short_name" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_page_start" => "5" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1083 #items: array:1 [ 0 => App\Models\Book {#1049 #connection: "mysql" #table: "books" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:50 [ "id" => 1202 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_tree_default_status" => "tasks" "field_pages_status" => null "field_subject" => Illuminate\Database\Eloquent\Collection {#1051 #items: array:1 [ 0 => App\Models\Term {#1048 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:10 [ "id" => 6493 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Физика" "field_abbreviated_name" => null "field_cases" => array:6 [ …6] "field_foreign_lang_name" => null "field_short_name" => null "field_subject_type" => "technical_subject" "field_translit" => "fizika" ] #original: array:10 [ "id" => 6493 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Физика" "field_abbreviated_name" => null "field_cases" => array:6 [ …6] "field_foreign_lang_name" => null "field_short_name" => null "field_subject_type" => "technical_subject" "field_translit" => "fizika" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_class" => Illuminate\Database\Eloquent\Collection {#1052 #items: array:1 [ 0 => App\Models\Term {#1053 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 5458 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "9" "field_cases" => array:6 [ …6] "field_translit" => "devjatyj" ] #original: array:6 [ "id" => 5458 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "9" "field_cases" => array:6 [ …6] "field_translit" => "devjatyj" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_publisher" => Illuminate\Database\Eloquent\Collection {#1054 #items: array:1 [ 0 => App\Models\Term {#1055 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 5174 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Вентана-граф" "field_cases" => null "field_translit" => "ventana-graf" ] #original: array:6 [ "id" => 5174 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Вентана-граф" "field_cases" => null "field_translit" => "ventana-graf" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_author" => Illuminate\Database\Eloquent\Collection {#1056 #items: array:3 [ 0 => App\Models\Term {#1057 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:12 [ "id" => 4180 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Грачев" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Александр" "field_patronymic" => "Васильевич" "field_surname_rp" => null ] #original: array:12 [ "id" => 4180 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Грачев" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Александр" "field_patronymic" => "Васильевич" "field_surname_rp" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 1 => App\Models\Term {#1058 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:12 [ "id" => 5484 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Погожев" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Владимир" "field_patronymic" => "Александрович" "field_surname_rp" => null ] #original: array:12 [ "id" => 5484 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Погожев" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Владимир" "field_patronymic" => "Александрович" "field_surname_rp" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 2 => App\Models\Term {#1059 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:12 [ "id" => 3888 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Боков" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Павел" "field_patronymic" => "Юрьевич" "field_surname_rp" => null ] #original: array:12 [ "id" => 3888 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Боков" "field_bio" => null "field_degree_rp" => null "field_foreign_lang_name" => null "field_foreign_lang_patronymic" => null "field_foreign_lang_surname" => null "field_name" => "Павел" "field_patronymic" => "Юрьевич" "field_surname_rp" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_author_foreign" => Illuminate\Database\Eloquent\Collection {#1060 #items: [] #escapeWhenCastingToString: false } "field_book_type" => Illuminate\Database\Eloquent\Collection {#1061 #items: array:1 [ 0 => App\Models\Term {#1062 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:10 [ "id" => 6671 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Учебник" "field_book_type_foreign" => null "field_cases" => array:6 [ …6] "field_plural_form" => null "field_short_name" => null "field_short_name_foreign" => null "field_translit" => "uchebnik" ] #original: array:10 [ "id" => 6671 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Учебник" "field_book_type_foreign" => null "field_cases" => array:6 [ …6] "field_plural_form" => null "field_short_name" => null "field_short_name_foreign" => null "field_translit" => "uchebnik" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_country" => Illuminate\Database\Eloquent\Collection {#1063 #items: array:1 [ 0 => App\Models\Term {#1064 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 9 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Россия" "field_cases" => array:6 [ …6] "field_translit" => "rossiya" ] #original: array:6 [ "id" => 9 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Россия" "field_cases" => array:6 [ …6] "field_translit" => "rossiya" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_city" => Illuminate\Database\Eloquent\Collection {#1065 #items: array:1 [ 0 => App\Models\Term {#1066 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 15 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Москва" "field_cases" => array:6 [ …6] "field_translit" => "moskva" ] #original: array:6 [ "id" => 15 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Москва" "field_cases" => array:6 [ …6] "field_translit" => "moskva" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_series" => Illuminate\Database\Eloquent\Collection {#1067 #items: array:1 [ 0 => App\Models\Term {#1068 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:8 [ "id" => 4697 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "алгоритм успеха" "field_cases" => null "field_foreign_lang_series" => null "field_transcription_eng" => null "field_translit" => "algoritm uspekha" ] #original: array:8 [ "id" => 4697 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "алгоритм успеха" "field_cases" => null "field_foreign_lang_series" => null "field_transcription_eng" => null "field_translit" => "algoritm uspekha" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_umk" => Illuminate\Database\Eloquent\Collection {#1069 #items: [] #escapeWhenCastingToString: false } "field_level_of_education" => Illuminate\Database\Eloquent\Collection {#1070 #items: [] #escapeWhenCastingToString: false } "field_standart_of_education" => Illuminate\Database\Eloquent\Collection {#1071 #items: array:1 [ 0 => App\Models\Term {#1072 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:10 [ "id" => 6706 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "ФГОС (старый)" "field_cases" => array:6 [ …6] "field_color" => null "field_end_year" => "2022" "field_start_year" => "2019" "field_translit" => "fgos-old" "field_type" => null ] #original: array:10 [ "id" => 6706 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "ФГОС (старый)" "field_cases" => array:6 [ …6] "field_color" => null "field_end_year" => "2022" "field_start_year" => "2019" "field_translit" => "fgos-old" "field_type" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_publication_number" => "2" "field_publication_type" => Illuminate\Database\Eloquent\Collection {#1073 #items: array:1 [ 0 => App\Models\Term {#1074 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 6900 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "доработанное" "field_cases" => array:6 [ …6] "field_translit" => "dorabotannoe" ] #original: array:6 [ "id" => 6900 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "доработанное" "field_cases" => array:6 [ …6] "field_translit" => "dorabotannoe" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_under_the_edition" => Illuminate\Database\Eloquent\Collection {#1075 #items: [] #escapeWhenCastingToString: false } "field_under_the_edition_degree" => null "field_cover_description" => "изображено здание и радуга" "field_publication_year" => "2012" "field_publication_year_until" => null "field_part" => "" "field_part_writing" => "" "field_second_foreign_language" => null "field_for_whom" => "Учебник для учащихся общеобразовательных организаций" "field_allowed" => null "field_reserve_field" => null "field_link_to_source" => null "field_tasks_count" => "580" "field_priority" => null "field_default_folder" => "/fizika_09/grachev-u/" "field_isbn" => "978-5-360-07412-0" "field_cover" => array:1 [ 0 => "/media/fizika_09/grachev-u/covers/cover1.webp?ts=1759082140" ] "field_cover_alts" => array:1 [ 0 => "" ] "field_covers" => array:1 [ 0 => array:4 [ "path" => "/media/fizika_09/grachev-u/covers/cover1.webp?ts=1759082140" "alt" => "" "width" => "2294" "height" => "3039" ] ] "field_popular_book" => "0" "field_recommended_books" => Illuminate\Database\Eloquent\Collection {#1076 #items: [] #escapeWhenCastingToString: false } "field_new_book" => Illuminate\Database\Eloquent\Collection {#1077 #items: [] #escapeWhenCastingToString: false } "field_old_book" => Illuminate\Database\Eloquent\Collection {#1078 #items: [] #escapeWhenCastingToString: false } "field_url" => "/9-klass/fizika/grachev-uchebnik" "field_cover_color" => Illuminate\Database\Eloquent\Collection {#1079 #items: array:1 [ 0 => App\Models\Term {#1080 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 49 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "синий" "field_cases" => array:6 [ …6] "field_translit" => "siniy" ] #original: array:6 [ "id" => 49 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "синий" "field_cases" => array:6 [ …6] "field_translit" => "siniy" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "breadcrumbs" => array:3 [ "class" => 380 "subject" => 556 "class_subject" => 493 ] ] #original: array:50 [ "id" => 1202 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_tree_default_status" => "tasks" "field_pages_status" => null "field_subject" => Illuminate\Database\Eloquent\Collection {#1051} "field_class" => Illuminate\Database\Eloquent\Collection {#1052} "field_publisher" => Illuminate\Database\Eloquent\Collection {#1054} "field_author" => Illuminate\Database\Eloquent\Collection {#1056} "field_author_foreign" => Illuminate\Database\Eloquent\Collection {#1060} "field_book_type" => Illuminate\Database\Eloquent\Collection {#1061} "field_country" => Illuminate\Database\Eloquent\Collection {#1063} "field_city" => Illuminate\Database\Eloquent\Collection {#1065} "field_series" => Illuminate\Database\Eloquent\Collection {#1067} "field_umk" => Illuminate\Database\Eloquent\Collection {#1069} "field_level_of_education" => Illuminate\Database\Eloquent\Collection {#1070} "field_standart_of_education" => Illuminate\Database\Eloquent\Collection {#1071} "field_publication_number" => "2" "field_publication_type" => Illuminate\Database\Eloquent\Collection {#1073} "field_under_the_edition" => Illuminate\Database\Eloquent\Collection {#1075} "field_under_the_edition_degree" => null "field_cover_description" => "изображено здание и радуга" "field_publication_year" => "2012" "field_publication_year_until" => null "field_part" => "" "field_part_writing" => "" "field_second_foreign_language" => null "field_for_whom" => "Учебник для учащихся общеобразовательных организаций" "field_allowed" => null "field_reserve_field" => null "field_link_to_source" => null "field_tasks_count" => "580" "field_priority" => null "field_default_folder" => "/fizika_09/grachev-u/" "field_isbn" => "978-5-360-07412-0" "field_cover" => array:1 [ 0 => "/media/fizika_09/grachev-u/covers/cover1.webp?ts=1759082140" ] "field_cover_alts" => array:1 [ 0 => "" ] "field_covers" => array:1 [ 0 => array:4 [ "path" => "/media/fizika_09/grachev-u/covers/cover1.webp?ts=1759082140" "alt" => "" "width" => "2294" "height" => "3039" ] ] "field_popular_book" => "0" "field_recommended_books" => Illuminate\Database\Eloquent\Collection {#1076} "field_new_book" => Illuminate\Database\Eloquent\Collection {#1077} "field_old_book" => Illuminate\Database\Eloquent\Collection {#1078} "field_url" => "/9-klass/fizika/grachev-uchebnik" "field_cover_color" => Illuminate\Database\Eloquent\Collection {#1079} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "breadcrumbs" => array:3 [ "class" => 380 "subject" => 556 "class_subject" => 493 ] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "branch_parent" => Illuminate\Database\Eloquent\Collection {#1081 #items: [] #escapeWhenCastingToString: false } ] #original: array:24 [ "id" => 1437875 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Кинематика" "field_branch_order" => "1" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1050} "field_page_start" => "5" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1083} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1081} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "parent_branches" => Illuminate\Database\Eloquent\Collection {#1114 #items: array:3 [ 0 => App\Models\Branch {#1124 #connection: "mysql" #table: "branches" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1437875 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Кинематика" "field_branch_order" => "1" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1125 #items: array:1 [ 0 => App\Models\Term {#1047} ] #escapeWhenCastingToString: false } "field_page_start" => "5" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1126 #items: array:1 [ 0 => App\Models\Book {#1049} ] #escapeWhenCastingToString: false } "branch_parent" => Illuminate\Database\Eloquent\Collection {#1127 #items: [] #escapeWhenCastingToString: false } ] #original: array:24 [ "id" => 1437875 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Кинематика" "field_branch_order" => "1" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1125} "field_page_start" => "5" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1126} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1127} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 1 => App\Models\Branch {#1128 #connection: "mysql" #table: "branches" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1437885 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Перемещение при равномерном прямолинейном движении по плоскости" "field_branch_order" => "4" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1132 #items: array:1 [ 0 => App\Models\Term {#1129 #connection: "mysql" #table: "terms" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:7 [ "id" => 32 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Параграф" "field_cases" => array:6 [ …6] "field_page_check_not_needed" => null "field_short_name" => "§" ] #original: array:7 [ "id" => 32 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "name" => "Параграф" "field_cases" => array:6 [ …6] "field_page_check_not_needed" => null "field_short_name" => "§" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "field_page_start" => "22" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1131 #items: array:1 [ 0 => App\Models\Book {#1049} ] #escapeWhenCastingToString: false } "branch_parent" => Illuminate\Database\Eloquent\Collection {#1130 #items: array:1 [ 0 => App\Models\Branch {#1045} ] #escapeWhenCastingToString: false } ] #original: array:24 [ "id" => 1437885 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Перемещение при равномерном прямолинейном движении по плоскости" "field_branch_order" => "4" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1132} "field_page_start" => "22" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1131} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1130} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 2 => App\Models\Branch {#1133 #connection: "mysql" #table: "branches" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1437887 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Упражнения" "field_branch_order" => null "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1134 #items: [] #escapeWhenCastingToString: false } "field_page_start" => "26" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1135 #items: array:1 [ 0 => App\Models\Book {#1049} ] #escapeWhenCastingToString: false } "branch_parent" => Illuminate\Database\Eloquent\Collection {#1144 #items: array:1 [ 0 => App\Models\Branch {#1143 #connection: "mysql" #table: "branches" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1437885 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Перемещение при равномерном прямолинейном движении по плоскости" "field_branch_order" => "4" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1145 …2} "field_page_start" => "22" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1146 …2} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1147 …2} ] #original: array:24 [ "id" => 1437885 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Перемещение при равномерном прямолинейном движении по плоскости" "field_branch_order" => "4" "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1145 …2} "field_page_start" => "22" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1146 …2} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1147 …2} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } ] #original: array:24 [ "id" => 1437887 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_display_title" => "Упражнения" "field_branch_order" => null "field_url" => null "field_branch_type" => Illuminate\Database\Eloquent\Collection {#1134} "field_page_start" => "26" "field_branch_display" => "0" "field_branch_expanded" => "0" "field_display_branch_in_title" => "1" "field_display_task_interval" => "0" "field_display_branch_page" => "1" "field_branch_title_in_content" => "0" "field_navigation_title" => null "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_branch_cover" => [] "field_branch_covers" => [] "book" => Illuminate\Database\Eloquent\Collection {#1135} "branch_parent" => Illuminate\Database\Eloquent\Collection {#1144} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "content" => Illuminate\Database\Eloquent\Collection {#1038 #items: array:2 [ 0 => App\Models\Element {#1106 #connection: "mysql" #table: "elements" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:7 [ "id" => 1704951 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1096 #items: array:1 [ 0 => App\Models\Edition {#1104 #connection: "mysql" #table: "editions" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:21 [ "id" => 6112 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "title" => "Условие" "field_order" => "1" "field_publisher" => Illuminate\Database\Eloquent\Collection {#1102 …2} "field_content_type" => "free" "field_content_mode" => "text, image" "field_page_content_mode" => "image" "field_content_text_checked" => "0" "field_page_content_text_checked" => "0" "field_solution_author" => "Автор" "field_moderator" => "stas" "field_edition_type" => "statement" "field_root_dir" => "0-" "field_responsible" => Illuminate\Database\Eloquent\Collection {#1103 …2} "field_comment" => null "field_similar_book" => Illuminate\Database\Eloquent\Collection {#1101 …2} "field_process_formula" => "katex" "field_edition_group" => Illuminate\Database\Eloquent\Collection {#1100 …2} "field_content_source" => null ] #original: array:21 [ "id" => 6112 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "title" => "Условие" "field_order" => "1" "field_publisher" => Illuminate\Database\Eloquent\Collection {#1102 …2} "field_content_type" => "free" "field_content_mode" => "text, image" "field_page_content_mode" => "image" "field_content_text_checked" => "0" "field_page_content_text_checked" => "0" "field_solution_author" => "Автор" "field_moderator" => "stas" "field_edition_type" => "statement" "field_root_dir" => "0-" "field_responsible" => Illuminate\Database\Eloquent\Collection {#1103 …2} "field_comment" => null "field_similar_book" => Illuminate\Database\Eloquent\Collection {#1101 …2} "field_process_formula" => "katex" "field_edition_group" => Illuminate\Database\Eloquent\Collection {#1100 …2} "field_content_source" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "task" => array:2 [ "refs" => "1438068" "type" => "task" ] "text" => "<p><strong>2.</strong> Определите модули перемещений, изображённых на рис. 13.</p>" "img" => array:2 [ 0 => array:5 [ "name" => "2-1.jpg" "alt" => null "width" => "460" "height" => 69 "path" => "/media/fizika_09/grachev-u/0-04upr/2-1.webp?ts=1759503086" ] 1 => array:5 [ "name" => "2-2.jpg" "alt" => null "width" => "542" "height" => 320 "path" => "/media/fizika_09/grachev-u/0-04upr/2-2.webp?ts=1759503086" ] ] ] #original: array:7 [ "id" => 1704951 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1096} "task" => array:2 [ "refs" => "1438068" "type" => "task" ] "text" => "<p><strong>2.</strong> Определите модули перемещений, изображённых на рис. 13.</p>" "img" => array:2 [ 0 => array:5 [ "name" => "2-1.jpg" "alt" => null "width" => "460" "height" => 69 "path" => "/media/fizika_09/grachev-u/0-04upr/2-1.webp?ts=1759503086" ] 1 => array:5 [ "name" => "2-2.jpg" "alt" => null "width" => "542" "height" => 320 "path" => "/media/fizika_09/grachev-u/0-04upr/2-2.webp?ts=1759503086" ] ] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 1 => App\Models\Element {#1098 #connection: "mysql" #table: "elements" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 1812635 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1090 #items: array:1 [ 0 => App\Models\Edition {#1099 #connection: "mysql" #table: "editions" #primaryKey: "id" #keyType: "int" +incrementing: false #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:21 [ "id" => 6644 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "title" => "Решение" "field_order" => "2" "field_publisher" => Illuminate\Database\Eloquent\Collection {#1094 …2} "field_content_type" => "free" "field_content_mode" => "text" "field_page_content_mode" => "" "field_content_text_checked" => "0" "field_page_content_text_checked" => "0" "field_solution_author" => "Gemini 2.5 Pro" "field_moderator" => "tolik" "field_edition_type" => "solution" "field_root_dir" => "1-" "field_responsible" => Illuminate\Database\Eloquent\Collection {#1095 …2} "field_comment" => null "field_similar_book" => Illuminate\Database\Eloquent\Collection {#1092 …2} "field_process_formula" => "katex" "field_edition_group" => Illuminate\Database\Eloquent\Collection {#1093 …2} "field_content_source" => null ] #original: array:21 [ "id" => 6644 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "title" => "Решение" "field_order" => "2" "field_publisher" => Illuminate\Database\Eloquent\Collection {#1094 …2} "field_content_type" => "free" "field_content_mode" => "text" "field_page_content_mode" => "" "field_content_text_checked" => "0" "field_page_content_text_checked" => "0" "field_solution_author" => "Gemini 2.5 Pro" "field_moderator" => "tolik" "field_edition_type" => "solution" "field_root_dir" => "1-" "field_responsible" => Illuminate\Database\Eloquent\Collection {#1095 …2} "field_comment" => null "field_similar_book" => Illuminate\Database\Eloquent\Collection {#1092 …2} "field_process_formula" => "katex" "field_edition_group" => Illuminate\Database\Eloquent\Collection {#1093 …2} "field_content_source" => null ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "task" => array:2 [ "refs" => "1438068" "type" => "task" ] "text" => "<p><strong>Дано:</strong></p><p>Из рисунка 13 определим координаты начала и конца каждого вектора перемещения. Цена одного деления координатной сетки по осям X и Y равна 1 м.</p><p>Для вектора $ \vec{\Delta r_1} $: начальная точка $ r_{1нач} = (4; 2) $ м, конечная точка $ r_{1кон} = (1; 7) $ м.</p><p>Для вектора $ \vec{\Delta r_2} $: начальная точка $ r_{2нач} = (8; 6) $ м, конечная точка $ r_{2кон} = (13; 3) $ м.</p><p>Для вектора $ \vec{\Delta r_3} $: начальная точка $ r_{3нач} = (16; 7) $ м, конечная точка $ r_{3кон} = (16; 3) $ м.</p><p>Все данные представлены в системе СИ.</p><p><strong>Найти:</strong></p><p>Модули векторов перемещений: $ |\vec{\Delta r_1}|, |\vec{\Delta r_2}|, |\vec{\Delta r_3}| $.</p><p><strong>Решение:</strong></p><p>Модуль вектора перемещения $ \vec{\Delta r} $ равен длине отрезка, соединяющего начальное и конечное положение тела. Он вычисляется по теореме Пифагора через проекции вектора на оси координат $ \Delta x $ и $ \Delta y $:</p><p>$ |\vec{\Delta r}| = \sqrt{(\Delta x)^2 + (\Delta y)^2} $</p><p>где $ \Delta x = x_{кон} - x_{нач} $ и $ \Delta y = y_{кон} - y_{нач} $.</p><p><strong>1.</strong> Определение модуля вектора $ \vec{\Delta r_1} $</p><p>Найдем проекции вектора $ \vec{\Delta r_1} $ на оси координат:</p><p>$ \Delta x_1 = 1 \, м - 4 \, м = -3 \, м $</p><p>$ \Delta y_1 = 7 \, м - 2 \, м = 5 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_1}| = \sqrt{(\Delta x_1)^2 + (\Delta y_1)^2} = \sqrt{(-3)^2 + 5^2} = \sqrt{9 + 25} = \sqrt{34} \approx 5,83 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_1}| \approx 5,83 \, м. $</p><p><strong>2.</strong> Определение модуля вектора $ \vec{\Delta r_2} $</p><p>Найдем проекции вектора $ \vec{\Delta r_2} $ на оси координат:</p><p>$ \Delta x_2 = 13 \, м - 8 \, м = 5 \, м $</p><p>$ \Delta y_2 = 3 \, м - 6 \, м = -3 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_2}| = \sqrt{(\Delta x_2)^2 + (\Delta y_2)^2} = \sqrt{5^2 + (-3)^2} = \sqrt{25 + 9} = \sqrt{34} \approx 5,83 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_2}| \approx 5,83 \, м. $</p><p><strong>3.</strong> Определение модуля вектора $ \vec{\Delta r_3} $</p><p>Найдем проекции вектора $ \vec{\Delta r_3} $ на оси координат:</p><p>$ \Delta x_3 = 16 \, м - 16 \, м = 0 \, м $</p><p>$ \Delta y_3 = 3 \, м - 7 \, м = -4 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_3}| = \sqrt{(\Delta x_3)^2 + (\Delta y_3)^2} = \sqrt{0^2 + (-4)^2} = \sqrt{16} = 4 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_3}| = 4 \, м. $</p>" ] #original: array:6 [ "id" => 1812635 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1090} "task" => array:2 [ "refs" => "1438068" "type" => "task" ] "text" => "<p><strong>Дано:</strong></p><p>Из рисунка 13 определим координаты начала и конца каждого вектора перемещения. Цена одного деления координатной сетки по осям X и Y равна 1 м.</p><p>Для вектора $ \vec{\Delta r_1} $: начальная точка $ r_{1нач} = (4; 2) $ м, конечная точка $ r_{1кон} = (1; 7) $ м.</p><p>Для вектора $ \vec{\Delta r_2} $: начальная точка $ r_{2нач} = (8; 6) $ м, конечная точка $ r_{2кон} = (13; 3) $ м.</p><p>Для вектора $ \vec{\Delta r_3} $: начальная точка $ r_{3нач} = (16; 7) $ м, конечная точка $ r_{3кон} = (16; 3) $ м.</p><p>Все данные представлены в системе СИ.</p><p><strong>Найти:</strong></p><p>Модули векторов перемещений: $ |\vec{\Delta r_1}|, |\vec{\Delta r_2}|, |\vec{\Delta r_3}| $.</p><p><strong>Решение:</strong></p><p>Модуль вектора перемещения $ \vec{\Delta r} $ равен длине отрезка, соединяющего начальное и конечное положение тела. Он вычисляется по теореме Пифагора через проекции вектора на оси координат $ \Delta x $ и $ \Delta y $:</p><p>$ |\vec{\Delta r}| = \sqrt{(\Delta x)^2 + (\Delta y)^2} $</p><p>где $ \Delta x = x_{кон} - x_{нач} $ и $ \Delta y = y_{кон} - y_{нач} $.</p><p><strong>1.</strong> Определение модуля вектора $ \vec{\Delta r_1} $</p><p>Найдем проекции вектора $ \vec{\Delta r_1} $ на оси координат:</p><p>$ \Delta x_1 = 1 \, м - 4 \, м = -3 \, м $</p><p>$ \Delta y_1 = 7 \, м - 2 \, м = 5 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_1}| = \sqrt{(\Delta x_1)^2 + (\Delta y_1)^2} = \sqrt{(-3)^2 + 5^2} = \sqrt{9 + 25} = \sqrt{34} \approx 5,83 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_1}| \approx 5,83 \, м. $</p><p><strong>2.</strong> Определение модуля вектора $ \vec{\Delta r_2} $</p><p>Найдем проекции вектора $ \vec{\Delta r_2} $ на оси координат:</p><p>$ \Delta x_2 = 13 \, м - 8 \, м = 5 \, м $</p><p>$ \Delta y_2 = 3 \, м - 6 \, м = -3 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_2}| = \sqrt{(\Delta x_2)^2 + (\Delta y_2)^2} = \sqrt{5^2 + (-3)^2} = \sqrt{25 + 9} = \sqrt{34} \approx 5,83 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_2}| \approx 5,83 \, м. $</p><p><strong>3.</strong> Определение модуля вектора $ \vec{\Delta r_3} $</p><p>Найдем проекции вектора $ \vec{\Delta r_3} $ на оси координат:</p><p>$ \Delta x_3 = 16 \, м - 16 \, м = 0 \, м $</p><p>$ \Delta y_3 = 3 \, м - 7 \, м = -4 \, м $</p><p>Теперь вычислим модуль вектора:</p><p>$ |\vec{\Delta r_3}| = \sqrt{(\Delta x_3)^2 + (\Delta y_3)^2} = \sqrt{0^2 + (-4)^2} = \sqrt{16} = 4 \, м. $</p><p><strong>Ответ:</strong> $ |\vec{\Delta r_3}| = 4 \, м. $</p>" ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "next" => array:2 [ "refs" => "1438069" "type" => "task" ] "previous" => array:2 [ "refs" => "1438067" "type" => "task" ] "book" => Illuminate\Database\Eloquent\Collection {#1109 #items: array:1 [ 0 => App\Models\Book {#1049} ] #escapeWhenCastingToString: false } "page" => Illuminate\Database\Eloquent\Collection {#1040 #items: array:1 [ 0 => App\Models\BookPage {#1111 #connection: "mysql" #table: "book_pages" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:21 [ "id" => 1437532 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_url" => "/9-klass/fizika/grachev-uchebnik/page-26" "field_display_title" => "26" "field_folder" => "1" "field_image_name" => "26" "field_branch_parent" => Illuminate\Database\Eloquent\Collection {#1091 #items: [] #escapeWhenCastingToString: false } "field_weight" => "0" "field_book_parent" => Illuminate\Database\Eloquent\Collection {#1087 #items: array:1 [ 0 => App\Models\Book {#1049} ] #escapeWhenCastingToString: false } "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "edition_groups" => Illuminate\Database\Eloquent\Collection {#1089 #items: [] #escapeWhenCastingToString: false } "content" => Illuminate\Database\Eloquent\Collection {#1115 #items: array:1 [ 0 => App\Models\Element {#1039 #connection: "mysql" #table: "elements" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:6 [ "id" => 1705528 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1113 …2} "book_page" => array:2 [ …2] "img" => array:1 [ …1] ] #original: array:6 [ "id" => 1705528 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "edition" => Illuminate\Database\Eloquent\Collection {#1113 …2} "book_page" => array:2 [ …2] "img" => array:1 [ …1] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } "next" => array:2 [ "refs" => "1437533" "type" => "book_page" ] "previous" => array:2 [ "refs" => "1437531" "type" => "book_page" ] "tasks" => Illuminate\Database\Eloquent\Collection {#1208 #items: array:9 [ 0 => App\Models\Task {#1224 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438062 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-1" "field_display_title" => "1" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1225 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1226 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1227 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1308 …2} "content" => Illuminate\Database\Eloquent\Collection {#1265 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1299 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438062 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-1" "field_display_title" => "1" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1225 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1226 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1227 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1308 …2} "content" => Illuminate\Database\Eloquent\Collection {#1265 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1299 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 1 => App\Models\Task {#1301 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438063 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1315 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1298 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1305 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1302 …2} "content" => Illuminate\Database\Eloquent\Collection {#1306 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1287 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438063 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1315 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1298 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1305 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1302 …2} "content" => Illuminate\Database\Eloquent\Collection {#1306 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1287 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 2 => App\Models\Task {#1294 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438064 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-3" "field_display_title" => "3" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1269 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1285 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1290 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1291 …2} "content" => Illuminate\Database\Eloquent\Collection {#1292 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1277 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438064 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-3" "field_display_title" => "3" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1269 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1285 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1290 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1291 …2} "content" => Illuminate\Database\Eloquent\Collection {#1292 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1277 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 3 => App\Models\Task {#1282 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438065 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-4" "field_display_title" => "4" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1289 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1275 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1279 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1280 …2} "content" => Illuminate\Database\Eloquent\Collection {#1276 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1228 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438065 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-4" "field_display_title" => "4" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1289 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1275 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1279 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1280 …2} "content" => Illuminate\Database\Eloquent\Collection {#1276 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1228 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 4 => App\Models\Task {#1303 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438066 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-5" "field_display_title" => "5" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1278 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1231 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1266 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1304 …2} "content" => Illuminate\Database\Eloquent\Collection {#1268 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1254 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438066 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04vopr-5" "field_display_title" => "5" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1278 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1231 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1266 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1304 …2} "content" => Illuminate\Database\Eloquent\Collection {#1268 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1254 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 5 => App\Models\Task {#1260 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438067 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-1" "field_display_title" => "1" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1267 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1253 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1256 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1259 …2} "content" => Illuminate\Database\Eloquent\Collection {#1258 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1243 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438067 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-1" "field_display_title" => "1" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1267 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1253 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1256 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1259 …2} "content" => Illuminate\Database\Eloquent\Collection {#1258 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1243 …2} "page" => array:2 [ …2] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } 6 => App\Models\Task {#1249 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ "id" => 1438068 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1257 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1242 …2} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1244 …2} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1246 …2} "content" => Illuminate\Database\Eloquent\Collection {#1245 …2} "next" => array:2 [ …2] "previous" => array:2 [ …2] "book" => Illuminate\Database\Eloquent\Collection {#1247 …2} "page" => array:2 [ …2] ] #original: array:24 [ "id" => 1438068 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1257 …2} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1242 …2} …7 ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ …1] } 7 => App\Models\Task {#1235 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ …24] #original: array:24 [ …24] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ …1] } 8 => App\Models\Task {#1307 #connection: "mysql" #table: "tasks" #primaryKey: "id" #keyType: "int" +incrementing: true #with: [] #withCount: [] +preventsLazyLoading: false #perPage: 15 +exists: true +wasRecentlyCreated: false #escapeWhenCastingToString: false #attributes: array:24 [ …24] #original: array:24 [ …24] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ …1] } ] #escapeWhenCastingToString: false } ] #original: array:21 [ "id" => 1437532 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_url" => "/9-klass/fizika/grachev-uchebnik/page-26" "field_display_title" => "26" "field_folder" => "1" "field_image_name" => "26" "field_branch_parent" => Illuminate\Database\Eloquent\Collection {#1091} "field_weight" => "0" "field_book_parent" => Illuminate\Database\Eloquent\Collection {#1087} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "edition_groups" => Illuminate\Database\Eloquent\Collection {#1089} "content" => Illuminate\Database\Eloquent\Collection {#1115} "next" => array:2 [ "refs" => "1437533" "type" => "book_page" ] "previous" => array:2 [ "refs" => "1437531" "type" => "book_page" ] "tasks" => Illuminate\Database\Eloquent\Collection {#1208} ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] } ] #escapeWhenCastingToString: false } ] #original: array:24 [ "id" => 1438068 "created_at" => "2026-04-10 13:58:26" "updated_at" => null "field_page_start" => "26" "field_page_end" => null "field_url" => "/9-klass/fizika/grachev-uchebnik/04upr-2" "field_display_title" => "2" "field_outside_task" => null "field_task_type" => Illuminate\Database\Eloquent\Collection {#1037} "field_metatags_title" => null "field_metatags_description" => null "field_h1" => null "field_description_top" => null "field_description_bottom" => null "field_match" => null "breadcrumbs" => [] "edition_groups" => Illuminate\Database\Eloquent\Collection {#1035} "top_parent_branch" => Illuminate\Database\Eloquent\Collection {#1046} "parent_branches" => Illuminate\Database\Eloquent\Collection {#1114} "content" => Illuminate\Database\Eloquent\Collection {#1038} "next" => array:2 [ "refs" => "1438069" "type" => "task" ] "previous" => array:2 [ "refs" => "1438067" "type" => "task" ] "book" => Illuminate\Database\Eloquent\Collection {#1109} "page" => array:2 [ "refs" => "1437532" "type" => "book_page" ] ] #changes: [] #casts: [] #classCastCache: [] #attributeCastCache: [] #dateFormat: null #appends: [] #dispatchesEvents: [] #observables: [] #relations: [] #touches: [] +timestamps: true +usesUniqueIds: false #hidden: [] #visible: [] #fillable: [] #guarded: array:1 [ 0 => "*" ] }
№2 (с. 26)
Условие. №2 (с. 26)
скриншот условия
2. Определите модули перемещений, изображённых на рис. 13.
Решение. №2 (с. 26)
Дано:
Из рисунка 13 определим координаты начала и конца каждого вектора перемещения. Цена одного деления координатной сетки по осям X и Y равна 1 м.
Для вектора $ \vec{\Delta r_1} $: начальная точка $ r_{1нач} = (4; 2) $ м, конечная точка $ r_{1кон} = (1; 7) $ м.
Для вектора $ \vec{\Delta r_2} $: начальная точка $ r_{2нач} = (8; 6) $ м, конечная точка $ r_{2кон} = (13; 3) $ м.
Для вектора $ \vec{\Delta r_3} $: начальная точка $ r_{3нач} = (16; 7) $ м, конечная точка $ r_{3кон} = (16; 3) $ м.
Все данные представлены в системе СИ.
Найти:
Модули векторов перемещений: $ |\vec{\Delta r_1}|, |\vec{\Delta r_2}|, |\vec{\Delta r_3}| $.
Решение:
Модуль вектора перемещения $ \vec{\Delta r} $ равен длине отрезка, соединяющего начальное и конечное положение тела. Он вычисляется по теореме Пифагора через проекции вектора на оси координат $ \Delta x $ и $ \Delta y $:
$ |\vec{\Delta r}| = \sqrt{(\Delta x)^2 + (\Delta y)^2} $
где $ \Delta x = x_{кон} - x_{нач} $ и $ \Delta y = y_{кон} - y_{нач} $.
1. Определение модуля вектора $ \vec{\Delta r_1} $
Найдем проекции вектора $ \vec{\Delta r_1} $ на оси координат:
$ \Delta x_1 = 1 \, м - 4 \, м = -3 \, м $
$ \Delta y_1 = 7 \, м - 2 \, м = 5 \, м $
Теперь вычислим модуль вектора:
$ |\vec{\Delta r_1}| = \sqrt{(\Delta x_1)^2 + (\Delta y_1)^2} = \sqrt{(-3)^2 + 5^2} = \sqrt{9 + 25} = \sqrt{34} \approx 5,83 \, м. $
Ответ: $ |\vec{\Delta r_1}| \approx 5,83 \, м. $
2. Определение модуля вектора $ \vec{\Delta r_2} $
Найдем проекции вектора $ \vec{\Delta r_2} $ на оси координат:
$ \Delta x_2 = 13 \, м - 8 \, м = 5 \, м $
$ \Delta y_2 = 3 \, м - 6 \, м = -3 \, м $
Теперь вычислим модуль вектора:
$ |\vec{\Delta r_2}| = \sqrt{(\Delta x_2)^2 + (\Delta y_2)^2} = \sqrt{5^2 + (-3)^2} = \sqrt{25 + 9} = \sqrt{34} \approx 5,83 \, м. $
Ответ: $ |\vec{\Delta r_2}| \approx 5,83 \, м. $
3. Определение модуля вектора $ \vec{\Delta r_3} $
Найдем проекции вектора $ \vec{\Delta r_3} $ на оси координат:
$ \Delta x_3 = 16 \, м - 16 \, м = 0 \, м $
$ \Delta y_3 = 3 \, м - 7 \, м = -4 \, м $
Теперь вычислим модуль вектора:
$ |\vec{\Delta r_3}| = \sqrt{(\Delta x_3)^2 + (\Delta y_3)^2} = \sqrt{0^2 + (-4)^2} = \sqrt{16} = 4 \, м. $
Ответ: $ |\vec{\Delta r_3}| = 4 \, м. $
